Speed
|
Up to 98 ft/min (30 m/min) in 4-color mode Up to 130 ft/min (40 m/min) in Enhanced Productivity Mode Up to 196 ft/min (60 m/min) in 1- or 2-color mode |
Resolution
|
812 dpi at 8 bit; addressability: 2438 x 2438 dpi HDI (High Definition Imaging) |
Micro-lines Resolution
|
175, 180, 196, 210 lpi |
Print/Non-print area
|
12.59 x 38.58 in (320 x 980 mm) maximum |
Substrate Thickness
|
0.5 to 18 pt. (12 to 450 microns) |
Substrates
|
Pressure-sensitive label stock, paper, unsupported films, and paperboard |
Paper Size
|
web width: Max. width: 13.39 in (340 mm) / Min. width: 7.87 in (200 mm) |
Unwinder
|
Input roll max. diameter: 39.37 in (1000 mm) Core inside diameter: • Standard: 3 in (76.2 mm) • Optional: 6 in (152.4 mm) Max. roll weight: 595 lb (270 kg) |
Rewinder
|
27.56 in (700 mm) max. roll diameter |
Spec3
|
HP Production Pro for Indigo Label & Packaging |
Dimensions (L x W x H)
|
Length: 228 in (5780 mm), Width: 155 in (3940 mm), Height: 83 in (2108 mm); Inline Priming Unit: Length: 55 in (1410 mm); Width: 61 in (1560 mm); Height: 40 in (1760 mm) |
Weight
|
weight 12,157 lb (5400 kg); Inline Priming Unit: 4000 lb (1800 kg) |
Ink
|
HP Indigo ElectroInks, Standard 4-color printing- Cyan, Magenta, Yellow, and Black, Additional process inks- Standard White, Premium White, White for Sleeves, Fade Resistant Yellow, Fade Resistant Magenta, Fluorescent Pink/Yellow/Orange/Green, HP Indigo Invisible ElectroInks (Yellow/Blue/Red/Green). HP Indigo ElectroInk Silver, HP IndiChrome 6-color printing- Cyan, Magenta, Yellow, Black, Orange, and Violet, HP IndiChrome Plus 7-color printing- Cyan, Magenta, Yellow, Black, Orange, and Violet, HP IndiChrome off-press spot inks- HP IndiChrome Ink Mixing System (IMS) for spot color creation using CMYK as well as Orange, Violet, Green, Reflex Blue, Rhodamine Red, Bright Yellow, and Transparent, PANTONE® colors- Supports PANTONE PLUS®, PANTONE MATCHING SYSTEM®, PANTONE Goe™ HP Professional PANTONE Emulation Technology using CMYK on-press; HP IndiChrome on-press; HP IndiChrome Plus on-press; HP IndiChrome off-press (IMS) for achieving up to 97% of the PANTONE® color range. |
Option
|
Enhanced Productivity Mode- Enables three-color EPM printing (Cyan, Magenta, Yellow), Inline Priming Unit (ILP**)- Enables easy on-demand treatment of substrates, Configurations- Dual mode inline finishing connectivity kit, flexible packaging packer arm support in rewinder, Automatic Alert Agent (AAA), Color Automation Package, Print server options- PrintOS Production Pro for Labels and Packaging, Reinsertion- Simplex and duplex capability |
