TechNova Imaging Systems. Eros

# Images are for illustration purpose only

Eros

Third Generation UV CtP Plate

Eros is a third generation UV CtP plate especially designed for hi-resolution, hi-speed imaging on all popular UV CtP plate setters, using Ultra-Violet laser diode technology. It is fully compatible with all popular processors too. Eros is significantly superior to the second generation UV CtP plates with enhanced exposing and processing latitude. Eros is capable of reproducing 2%-98% dots, 200 lpi and is FM screening capable.

(Note: Not recommended for use as Analog PS Plate)

SKU Code	Description	UOM	Price	No. of Packs	Quantity	Total Price(INR)	Billing Location	Delete

Features & Benefits:
- High sensitivity plate ensures higher throughput and hence improved productivity.
- Excellent Image contrast resulting in early detection of errors and defects, if any
- Outstanding exposure and processor latitude helps the plate to perform optimally in varying pre-press conditions
- Compatible to baking process with Thermotect/RC 510 to increase run-length
- Excellent resistance to alcohol and press chemicals for robust press performance with higher run-length
- Each plate carries an unique printed identification number for quality assurance
Storage & Handling:
- Storage & Handling : 20^oC - 25^oC; 30% to 70% RH. If the storage temperature differs significantly from plateroom temperature, the plates should be acclimatized in their original packaging for at least 12 hours before unpacking and processing the plates. Always open the packaging under recommended room illumination.
- Recommended plateroom conditions : Operating temperatures 23^oC (±2^oC); 40% to 70% RH.
- Shelf-life : 18 months (from the date of manufacturing) under recommended storage conditions.

Product Specifications:

Products specifications

Attribute name	Attribute value
Plate Type	UV CtP Positive-working
Substrate	Litho-grade aluminium, electrochemically grained and anodised
Gauge (mm)	0.15 , 0.28 , 0.30
Safe light	Yellow Safe light & UV protection on windows
Spectral Sensitivity	Ultra-Violet laser diode compatible (405 nm)
Run-length	Upto 100,000 impressions unbaked (Actual run-length may vary according to press conditions, ink & paper quality)
Manual Processing	Not recommended
Machine Processing	Spartan Developer with recommended dilution to be used on processors with chiller unit
Finishers	Unifin A solution
Deletion	NovaDelete P / Jiffy Deletion Fluid
Baking Solution	Thermotect / RC510
Storage after Processing	Unifin Finishing Solution for storage up to 24 hours; NovaKeepGum Solution for storage up to 3 months.
Plate Cleaner	lnstaKleen CtP, Instakleen HD (for Baked plates)
Fountain Solution	Compatible with all recommended fountain solutions and fount additives from TechNova
Press Wash	Compatible with all recommended washes from TechNova
Press Care	Compatible with all recommended Presscare solutions from TechNova

Based on your selection, you may be interested in the following items

Spartan

Third Generation UV CtP Plate

Spartan is a third generation UV CtP plate especially designed for hi-resolution, hi-speed imaging on the latest UV CtP plate setters using Ultra-Violet laser diode technology. It is significantly superior to the second generation UV CtP plate. Spartan ensures reproduction of 2%-98% dots at 200 lpi and is FM screening capable.

(Note: Not recommended for use as Analog PS Plate)
